30/09/2025

Connector clip for connector, natural, 4500pcs.
Art.-No. 151-02749 | 23MM11MMCCADPT-POM-NA

Copied
  • Easy to install by simply pushing into place
  • Connection can be released (non-destructive)
  • One fit tree foot part can be used for a variety of panel thicknesses
  • Disc covers the hole to prevent dust and dirt gaining access
Application The Connector Clips used here have been designed for electronic cables and cable sets used in the automotive industry. These parts are related to a connector and then secured to a surface depending on the requirement
Colour Natural (NA)
Material Polyacetal (POM)
PART DESCRIPTION 23MM11MMCCADPT-POM-NA
Package Content 4500pcs.
Package Content packed in bag
Type 23MM11MMCCADPT
Weight/Unit 0.002832kg
Height (H) 12.26mm
Length (L) 28.27mm
Width (W) 24.0mm
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
Operating Temperature -40 °C to +90 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
Country of Origin US
Customs Number 39269097
GTIN-13 / EAN 4031026731018
Packaging 1 - Type bag
Packaging 3 - Height (m) 0.20955m
Packaging 3 - Length (m) 0.5175m
Packaging 3 - Qty 4500
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0344
Packaging 3 - Weight (kg) 13.4kg
Packaging 3 - Width (m) 0.3175m
Packaging 4 - Height (m) 1.094m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 90000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.05
Packaging 4 - Weight (kg) 289.0kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 31162305
