XY60-PVC-BU
Art.-No. 172-04113 | XY60-PVC-BU |

This product is not available anymore.

Application Method	In order to speed up the application of a series of sleeves, a range of TJC applicator tools are available. Thread the required sleeves onto the applicator tool, insert the wire into the end of the tool and then simply slide the sleeves along the tool and onto the wire.
Colour	Blue (BU)
Material	Flexible Polyvinyl Chloride, cadmium free (PVC)
PART DESCRIPTION	XY60-PVC-BU
Pack Cont.	200m
Package Content packed in	bag
Type	XY60

Supplied ⌀ D min.	6.0mm
Wall (WT)	0.50mm

Dielectric Strength	40kV/mm
Dielectric Strength test method	IEC 60684 P2
Flammability	UL 94 V0 (1 mm)
Operating Temperature	-65 °C to +105 °C, intermittent +135 °C
ROHS compliant	Yes
Specifications
Specifications	BS-2848 Type 3, DEF STAN 59-15 Type D1b, IEC 684-3-101/104, UL 224
