Manual tensioning tool plastic housing : EVO9HT

EVO9 up to 13.5 mm strap width, Article number: 110-80004

Features

  • Standard grip span (90 mm) and short grip span (80 mm) available
  • Ergonomic, slip-proof handle for a comfortable and secure grip
  • Extremely low-maintenance
  • Fast and precise application with minimum effort (TLC-technology)
  • Convenient and simple tension adjustment
  • Integrated 3 position quick adjustment override (EVO9/EVO9SP/EVO9HT)
  • Housing made of resilient and lightweight glass fibre-reinforced polyester

Certifications & Approvals

Application

The EVO9HT is the high tension version of the EVO9 family. Developed for maximum tensile strength this tool performs between 120N and 516N. The tool was designed to apply HellermannTyton T120 and T250 cable ties with a maximum width of 13.5 mm (T250).

EVO9 up to 13.5 mm strap width is suitable for following markets and industries

Colour Red (RD), Black (BK)
Operation manually
Pack Cont. 1pc.
PART DESCRIPTION EVO9HT-MET/PL-BK/RD
Product Family EVO9 up to 13.5 mm strap width
Product Group Manual tensioning tool plastic housing
Short Description EVO 9HT High Tension Mechanical Hand Tool, Tension Range 27 lb to 116 lb, 1/pkg
Strap Thickness max. 2.0mm
Technical Description Tension Range 27 lb to 116 lb
Tension Setting Tools Adjustable
Tool property Manual clipping
Tool suitable cable tie material Plastic
Height (H) 135mm
Length (L) 191mm
Strap Width max. 13mm
Strap Width max. (G) 0.5"
Width (W) 33mm
Material Metal (MET), Plastic (PL)
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
EAN / GTIN 4031026511320
Weight 0.8lbs
Weight 0.36kg
ETIM 6.0 EC000453
ETIM 7.0 Key EC000453
UNSPSC Key 27112410
