24/10/2025

Cable tie tool for 2.5-4.8mm, pneumatic, 0.87kg, black
Art.-No. 110-07100 | MK7P-PA66GF30-BK |

Copied
Lightweight but very tough housing made of glass fiber-reinforced plastic.
The pneumatic tensioning tool MK7P for plastic cable ties with max. width of 4.8 mm.
The easy to use quick-set-knob.

    • Enhanced technology for better application of cable ties
    • Improved compressed air supply for faster tensioning piston movement
    • Shorter processing time and greater volume of connecting tie application
    • Genuine potential for rationalisation
    • Ergonomic design, moulded handle to prevent slippage, reduce operator fatigue
    • Lightweight but very tough housing made of glass fibre-reinforced plastic
    • Meets high industry standards
    • Tensionioning and cutting off cable ties flush with head by pressing one button
    • Smooth cut edge to prevent injuries
    • Automatic ejection of cut-off cable tie end
    • Three-level preset control to set tool tension
    • Optional safety cap to prevent tension setting from being changed by accident
    • (Important when bundling sensitive materials and maintaining process reliability)
    • Non-slip, comfortable grip, soft touch trigger, and one-touch tensioning/cut off
    • Very lightweight and easy to use on all cable ties 2.5 - 4.8 mm wide
    Add to watchlist
    Downloads
    Application The MK7P pneumatic bundling tool sets a new benchmark for the rational application of ties in the industrial production process. Improved compressed air supply moves the tensioning piston faster than in comparable tools.
    Air Pressure (max.) 6Bar
    Air Pressure (min.) 3Bar
    Air Pressure Psi (max.) 90Psi
    Air Supply non oiled, oiled
    Air att. Position lower air connection
    Colour Black (BK)
    Description MK7P
    For Cable Tie Width 2.5-4.8mm
    Material Polyamide 6.6, glass-fibre reinforced (PA66GF30)
    Number of cycles 1000000
    Operation pneumatic
    PART DESCRIPTION MK7P-PA66GF30-BK
    Package Content 1pc.
    Package Content packed in carton
    Product Family MK7P up to 4.8 mm strap width
    Product Group Pneumatic tensioning tool plastic housing
    Short Description Pneumatic tensioning tool up to 4.8 mm strap width
    Strap Thickness max. 1.5
    Tension force (N) 60-170N
    Tool property Automatic cut off
    Tool suitable cable tie material Plastic
    Type MK7P
    Weight/Unit 0.87kg
    for Air Pressure min - max 3 - 6 Bar
    Height (H) 170mm
    Hose Internal Diameter 4.0mm
    Length (L) 220mm
    Pawl Travel Stroke 1.0"
    Pawl Travel Stroke 2.54cm
    Strap Width max. 4.8mm
    Strap Width max. (G) 0.18"
    Tension Setting Adjustable
    Width (W) 40mm
    CE Certification No
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin US
    Customs Number 84671900
    Dimensions W x H x D 40 mm x 170 mm x
    GTIN-13 / EAN 4031026218045
    Packaging 1 - Height (m) 0.06m
    Packaging 1 - Length (m) 0.37m
    Packaging 1 - Qty 1
    Packaging 1 - Type carton
    Packaging 1 - Volume (m³) 0.00666m³
    Packaging 1 - Weight (kg) 1.37kg
    Packaging 1 - Width (m) 0.3m
    Packaging 2 - Height (m) 0.216m
    Packaging 2 - Length (m) 0.3048m
    Packaging 2 - Volume (m³) 0.0176m³
    Packaging 2 - Width (m) 0.267m
    Packaging 3 - Height (m) 0.04445m
    Packaging 3 - Length (m) 0.307975m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0032m³
    Packaging 3 - Width (m) 0.23495m
    ETIM 7.0 Key EC000453
    ETIM 8.0 Key EC000453
    ETIM 9.0 Key EC000453
    UNSPSC Key 27112410
    Cable tie guns Cable tie guns

    Cable tie guns

    From manual and pneumatic cable tie guns to automatic cable tie guns, Hellermanntyton offers a wide range of cable tie tensioning tools for a variety of requirements. Always reliable and comfortable and ideal for long-term use.
