Automatic Cable Tying Systems : AT2060

AT2060 Auto Tool, Article number: 103-00000

Features

  • Fast: Cable ties are installed quickly with one easy trigger depression, increasing productivity while decreasing labor costs.
  • Reliable: HellermannTyton's automatic cable tie systems have been tested to perform extremely consistently, without interruption to workflow.
  • Ergonomic: The ergonomic design of the automatic cable tie tool systems feature a comfortable grip, low weight, and easy trigger depression to reduce installer effort and strain while installing cable ties.
  • Providing Valuable Operator Feedback: Equipped with a self diagnostic LCD information screen, the automatic cable tie system easily guides the user through the cycles of cable tie installations.
  • Flexible Manufacturing Versatility: HellermannTyton's cable tie tool systems support principles of flexible manufacturing requirements and environments. This system can be used in handheld, bench mount, and overhead assembly configurations. The versatile overhead assembly option provides the ultimate integration into the customer's manufacturing area. HellermannTyton's autotool AT2060 is powered by a standard 110 AC 27V electrical outlet that the power supply converts to a low DC voltage for the tool.
  • Uniform Fastening Quality: HellermannTyton's automatic cable tie systems feature adjustable tension control to deliver consistent levels of cable tie fastening.
  • Range: HellermannTyton offers the widest range of automatic cable tie tool systems which cover cable tie tensile strengths of 18, 30 and 50 pounds with bundle diameters between 1/16" to over 3".

Certifications & Approvals

Application

Harness binding

Cable Ties T30RA30, T30RA3000
Colour Black (BK)
Mounting Screw Type M3
Operation electrical
Pack Cont. 1
Package Quantity per pcs.
PART DESCRIPTION AT2060-BK
Power Supply unit 85-265 VAC
Product Family AT2060 Auto Tool
Product Group Automatic Cable Tying Systems
Tool suitable cable tie material Plastic
Bundle ∅ max. 31.75mm
Bundle ∅ min. 1.50mm
Cycle Time 1.2s
Height (H) 269.7mm
Length (L) 361.2mm
Operational Voltage 27
Pawl Travel Stroke 3.175cm
Pawl Travel Stroke 1.25"
Power Supply Electrical with Power Pack
Strap Width max. (G) 0.14"
Strap Width max. (G) 3.6mm
Tension Force Continuously adjustable
Width (W) 66.4mm
ELV compliant (Article 4 - 2) YES
Hazardous good No
Specifications
EAN / GTIN 4944387970111
Weight 3.9lbs
Weight 1.8kg
