Aluminium frame mount, black, 5000pcs.


Art.-No. 151-04194

| AFLM20-2-POM-BK

 |

Copied

    • maximum ease of use
    • No need to screw it in place
    • Can be used with 20, 30 or 40 mm square frames from the major aluminum frame manufacturers
    Add to watchlist
    Downloads e-Learning
    Colour Black (BK)
    Material Polyacetal (POM)
    PART DESCRIPTION AFLM20-2-POM-BK
    Package Content 5000pcs.
    Package Content packed in bag
    Product Group Fixing elements for aluminium frames
    Short Description Mounts which are special designed for aluminum construction profiles
    Type AFLM20-2
    Typical Application Our aluminium frame mounts are specially designed for aluminium construction profiles. Theirs installation and handling is very simple. At every favoured place on the profile just with a quarter turn the mount is firmly fixed. Also it can be easily loosened and repositioned at any time. The mounts are custom developed for several aluminium construction profiles.
    Height (H) 12.6mm
    Length (L) 19.5mm
    Width (W) 13.5mm
    for Panel Thickness min - max 2.2 - 2.8 mm
    Flammability UL 94 V2
    Operating Temperature -40 °C to +90 °C
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    GTIN-13 / EAN 4031026741086
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
