Cable tie mount for screw fixation, Wmax=12.7mm, ⌀M6, M6 Screw, grey, 2500pcs.
Art.-No. 151-02891 | HDM6-TS-PA46-GY

The heavy duty mounts are designed for use with HellermannTyton’s heavy duty T250, T255 and wide strap cable ties to harness wires and hoses; however, they accept all standard cable ties up to .5" wide.
These mounts contain a small tab inside the mounting hole to temporarily engage the threads, which allows assemblers to pre-install the mount on a stud before securing with a washer and a nut.
The arched "H" profile of the saddle surface allows for a broad surface contact with the bundle, minimizing pinching and crushing of the bundles, and adjusts to a wide variety of bundle diameters.
The mounts are available in standard, medium and high torque versions.
The high torque version is designed for use with power-assisted impact wrenches and is molded with a metal bushing to withstand the forces required to tighten grade 8 bolts.

More products in this product group:

Application	These heavy duty mounts (HDM) have been primarily designed for use in the automotive and truck industry. Nowadays they can be found in a variety of applications requiring heavy duty mounting in areas like the railway, defence and/or agriculture industry.
Brand Family	HDM-Series
Color	Gray (GY)
PART DESCRIPTION	HDM6-TS-PA46-GY
Packaging Type	bag
Part No.	151-02891
Product family	Harness Clips
Product family	Products to screw
Type	HDM6-TS

Material	PA46
Material	Polyamide 4.6 (PA46)

Customs Number (Schedule B)	3926909988
Pkg. Qty.	2500Pieces
