Cable tie mount for magnetic use, white, 100pcs.
Art.-No. 151-03644
| MAGC10M-NDFEB35M/POM/ST-WH
Copied
- No drilling or extra hardware required – just position on steel surface.
- Magnetic mounts are reliable even in debris, dirt and oil.
- Use for permanent mounting or as a temporary installation tool.
- Reuse, 360-degree rotation and reposition capabilities allow for a flexible mounting solution.
- Easily remove without leaving residue behind.
| Color | White (WH) |
| Description | Magnetic clips are designed to route bundles by securing to steel surfaces without the need for a mounting hole. Simply attach the wire bundle by pushing it into the clip and position it onto the beam, metal joist, ceiling channel, conveyor frame, or other steel surface. The clips are simple to secure and can attach to surfaces contaminated with oil or debris. Ultra-strong neodymium magnets are ideal as a permanent mount or for temporary applications. Reuse and reposition them for ultimate flexibility without needing to replace or repurchase parts. |
| Key product features | removable, reusable |
| Magnetic pull strength (N) | 44N |
| Magnetic pull strength (kgf) | 4.49 |
| Magnetic pull strength (lb/ft) | 10lbf-ft |
| PART DESCRIPTION | MAGC10M-NDFEB35M/POM/ST-WH |
| Packaging Type | pack |
| Part No. | 151-03644 |
| Rotation (°) | 360° |
| Short Desc. | Magnetic Clip, Medium, 0.75", Neodymium Magnet/POM/ST, 10lb Pull Force, White, 100/bag |
| Type | MAGC10M |
| UV Resistant | No |
| Depth (imperial) | 0.23" |
| Depth (metric) | 5.7mm |
| Diameter (imperial) | 0.75" |
| Diameter (metric) | 19.0mm |
| Fixation Method | Magnet |
| Height (imperial) | 0.97" |
| Height (metric) | 24.7mm |
| Height 2 (imperial) | 0.8" |
| Height 2 (metric) | 20.2mm |
| Length (imperial) | 1.03" |
| Length (metric) | 26.2mm |
| Nominal Bundle Diameter (imperial) | 0.75 " |
| Nominal Bundle Diameter (metric) | 19.05 mm |
Download
| CE Certification | No |
| CSA Certified | Yes |
| Halogen Free | Yes |
| Material | NDFEB35M, POM, ST |
| Material | Neodymium alloy 35M (NDFEB35M), Polyacetal (POM), Steel (ST) |
| Operating Temperature | -40°F to +176°F (-40°C to +80°C) |
| Plenum Rating | AH-2 |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| Reusable (Yes/No) | Yes |
| UL File Number [Logo] | E64139 [cULus] |
| UL Listed (US and Canada) | Yes |
| UL Listed (US) | Yes |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
