Cable tie mount for adhesive use, Wmax=4.6mm, ⌀4.6 mm, #8 Screw, black, 500pcs.
Art.-No. 151-01632
| MB4A-PA66HIRHSUV-BK
Copied
- For use with HellermannTyton T18 - T50 cable ties to provide stability when securing bundles.
- 4-way opening allows cable ties to be installed parallel or perpendicular to bundles.
- The high-heat, high-bond adhesive is ideal for outdoor applications, with a static load weight of 1.1 lb.
- Two predrilled holes extend mounting options and solutions.
- Extended adhesive liner is easy to remove quickly.
More products in this product group:
| Application | Mount will adhere to medium and high surface energy paints, as well as a wide range of plastics commonly found in the automotive, heavy truck/equipment industries. |
| Brand Family | MB-Series |
| Color | Black (BK) |
| Description | MB4A4 adhesive mounts are for use with HellermannTyton T18 - T50 Series cable ties to provide stability when securing bundles. The high-heat, high-bond acrylic adhesive-backed mounts can be used to secure a bundle and have two predrilled holes to extend mounting options. |
| Max. Static Load (imperial) | 1.1lbf-ft |
| PART DESCRIPTION | MB4A-PA66HIRHSUV-BK |
| Packaging Type | pack |
| Part No. | 151-01632 |
| Product family | Adhesive Mount Cable Tie Bases |
| Product family | Self adhesive products |
| Short Desc. | High Heat High Bond Acrylic Adhesive Base, 1.12 x 1.12", Use T18-T50 Tie, PA66HIRHSUV, Black, 500/pkg |
| Type | MB4A |
| UV Resistant | Yes |
| Cable Ties | T18 - T50 |
| Fixation Method | Adhesive |
| Height (imperial) | .22" |
| Height (metric) | 5.6mm |
| Length (imperial) | 1.12" |
| Length (metric) | 28.5mm |
| Max. Cable Tie Width (imperial) | 0.18" |
| Max. Cable Tie Width (metric) | 4.6mm |
| Maximum Static Load (N) | 4.893N |
| Mounting Hole Centers (imperial) | 0.8" |
| Mounting Hole Diameter (imperial) | 0.18 " |
| Mounting Hole Diameter (metric) | 4.6 mm |
| Mounting Screw Type | #8 Screw |
| Width (imperial) | 1.12" |
| Width (metric) | 28.5mm |
Download
| Adhesive | Acrylic foam |
| Adhesive Operating Temperature | -40°F to +176°F (-40°C to +80°C) |
| CE Certification | No |
| CSA Certified | No |
| Flammability | UL 94 HB |
| Material | PA66HIRHSUV |
| Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV) |
| Operating Temperature | -40°F to +221°F (-40°C to +105°C) |
| Operating Temperature, 1000h | +320°F (+160°C) |
| Operating Temperature, 5000h | +257°F (+125°C) |
| Operating Temperature, 500h | +329°F (+165°C) |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
