Cable tie mount for screw fixation, Wmax=7.6mm, ⌀3.8 mm, #6 (M3) Screw, natural, 100pcs.
Art.-No. 151-25619 | MSMP6/6-PA66-NA

Mounting plates allow multiple bundles to run parallel.
The mounts are secured using two screws, while the bundles are attached using cable ties in any of the available slots.

More products in this product group:

Application	Many applications require each cable run to be firmly held in place but to be held separately from adjacent cable runs (example - control cabinets, machinery and military systems). The MP series of mounts can achieve this.
Brand Family	MSMP-Series
Color	Natural (NA)
Description	HellermannTyton mounting plates allow multiple cable to be run in parallel. The mount is secured with two screws and the cables are attached to the plate by using a cable tie through any of the available slots.
PART DESCRIPTION	MSMP6/6-PA66-NA
Packaging Type	pack
Part No.	MSMP6/69C2
Product family	Screw Mount Cable Tie Bases
Product family	Products to screw, Products for wires and hoses
Short Desc.	Cable Tie Mounting Plates, 9.6" x .62", .15" Hole Dia, .3" Max Tie Width, PA66, Natural, 100/pkg
Type	MSMP6/6


Cable Ties	T18 - T120
Fixation Method	Screw Mounting and Rivet
Height (imperial)	0.21"
Height (metric)	5.30mm
Length (imperial)	9.58"
Length (metric)	243.0mm
Max. Cable Tie Width (imperial)	0.3"
Max. Cable Tie Width (metric)	7.6mm
Mounting Hole Centers (imperial)	1.48"
Mounting Hole Diameter (imperial)	0.15 "
Mounting Hole Diameter (metric)	3.8 mm
Mounting Screw Type	#6 (M3) Screw
No. of bundles	6
Width (imperial)	0.62"
Width (metric)	15.7mm
