Cable tie mount for screw fixation, Wmax=12.7mm, ⌀8.0 mm, ⌀8.0 mm, 5/16" (M8) Screw, black, 500pcs.
Art.-No. 151-29701
| SAOM82-PA66HIRHSUV-BK
Copied
- Positions bundles off cross members and frame rails to prevent abrasion and chafing.
- Metal insert bushing accommodates high torque installation.
- Made with high impact, heat stabilized, and UV material ideal for trucking and heavy equipment environments.
More products in this product group:
| Application | This axial oval mount stands off bundles from frame rails and cross members to prevent them from rubbing and chafing. They can be perfectly used in combination with heavy duty cable ties up to 12.7 mm width – ideal to securely fix cables and wires in the railway and shipbuilding industry as well as in truck and agricultural vehicle construction. |
| Brand Family | SA-Series |
| Color | Black (BK) |
| Description | HellermannTyton’s axial oval mount stands off bundles from frame rails and cross members to prevent them from rubbing and chafing. The axial oval mount accommodates cable ties up to 0.5” wide. The hole on the mount was designed to fit a 5/16" bolt. |
| Key product features | vibration absorbing |
| PART DESCRIPTION | SAOM82-PA66HIRHSUV-BK |
| Packaging Type | pack |
| Part No. | SAOM820HIRHSH1 |
| Product family | Axial Oval Mounts |
| Product family | Products to screw |
| Short Desc. | Axial Oval Mount, 0.31" (8mm) Mounting Hole, PA66HIRHSUV, Black, 500/pkg |
| Type | SAOM82 |
| UV Resistant | Yes |
|
|
|
| Cable Ties | T50 - T250 |
| Fixation Method | Screw Mounting and Rivet |
| Height (imperial) | 1.40" |
| Height (metric) | 35.0mm |
| Length (imperial) | 1.40" |
| Length (metric) | 34.0mm |
| Max. Cable Tie Width (imperial) | 0.5" |
| Max. Cable Tie Width (metric) | 12.7mm |
| Min. Mounting Hole Diameter (imperial) | 0.31" |
| Mounting Hole Diameter (imperial) | 0.31 " |
| Mounting Hole Diameter (metric) | 8.0 mm |
| Mounting Hole Shape | Oval |
| Mounting Screw Type | 5/16" (M8) Screw |
| Stud Diameter (imperial) | 0.3125" |
| Stud Diameter (metric) | 8.0 mm |
| Width (imperial) | 1.0" |
| Width (metric) | 26.0mm |
Download
| CE Certification | No |
| CSA Certified | No |
| Flammability | UL 94 HB |
| Material | PA66HIRHSUV |
| Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV) |
| Operating Temperature | -40°F to +221°F (-40°C to +105°C) |
| Operating Temperature, 1000h | +320°F (+160°C) |
| Operating Temperature, 5000h | +257°F (+125°C) |
| Operating Temperature, 500h | +329°F (+165°C) |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
