Fixing tie for screw fixation, inside serrated, ⌀105.0mm, black, 1000pcs.
Art.-No. 156-02798 | T120RCPCM6-TS-SET-PA66HIRHS/PA66HS-BK |

Copied

    Add to watchlist
    Downloads
    Application Screw mount for screw fixation
    Colour Black (BK)
    Fixation Method Screw Mount
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS), Polyamide 6.6, heat stabilised (PA66HS)
    Min.Tensile Strength 535N
    Mounting Screw Type M6 Screw
    PART DESCRIPTION T120RCPCM6-TS-SET-PA66HIRHS/PA66HS-BK
    Package Content 1000pcs.
    Package Content packed in carton
    Product Family HDM-Series
    Product Group 2-Piece Fixing Ties for Heavy Duty Applications, for Screws
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T120RCPCM6-TS-SET
    Variant Inside Serrated
    Weight/Unit 0.003kg
    Bundle ⌀ 105.0mm
    Bundle ⌀ max. 105.0mm
    Length (L) 390.0mm
    Thickness (T) 1.9mm
    Width (W) 7.6mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    Customs Number 39269097
    GTIN-13 / EAN 4031026632025
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    Packaging 1 - Weight (kg) 1.500001kg
    Packaging 3 - Height (m) 0.22m
    Packaging 3 - Length (m) 0.57m
    Packaging 3 - Qty 1000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0489m³
    Packaging 3 - Weight (kg) 3.705002kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.244m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 20000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.194m³
    Packaging 4 - Weight (kg) 95.1kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
