Cable tie mount, ⌀4.2 mm, black, 100pcs.
Art.-No. 151-04551 | TMB4A-PA66-BK

Copied
  • This is a mount base that can be rotated after the fastening material has been fixed.
  • After being secured with a cable tie, it can be rotated up to about 90°, reducing stress on the cable.
Application Where speed, simplicity and a firm fixing base are required these self adhesive clips are ideal. Particularly suitable for use in control cabinets, telecoms equipment or domestic appliances where the use of holes, screws, or nuts and bolts is impractical or undesirable.
Colour Black (BK)
Fixation Method Screw Mounting and Adhesive
Material Polyamide 6.6 (PA66)
PART DESCRIPTION TMB4A-PA66-BK
Pack Cont. 100pcs.
Package Content packed in bag
Type TMB4A
Fixing Hole Centres (F) 20mm
Height (H) 5.8mm
Length (L) 28mm
Load max. 19.6N
Width (W) 28mm
for Hole ⌀ (FH) 4.2 mm
Flammability UL 94 V2
ROHS compliant Yes
Specifications
Country of Origin JP
GTIN-13 / EAN 4944387129915
ETIM 7.0 Key EC000449
ETIM 8.0 Key EC000449
ETIM 9.0 Key EC000449
UNSPSC Key 39121717
