Cable tie inside serrated, 101.6x2.5mm, ⌀1.6-13.0mm, black, 100pcs.
Art.-No. 112-51905 | CTT20R-PA66HS-BK

Copied
The Clamp Tie head design contains clamping rails to provide full circumferential compression around bundles.
The Clamp Tie head design contains clamping rails to provide full circumferential compression around bundles.
CTT series
The Clamp Tie head design contains clamping rails to provide full circumferential compression around bundles.
CTT Hose Ties
For secure fixing of round and solid shapes.
CTT60R.
The Clamp Tie head design contains clamping rails to provide full circumferential compression around bundles.
The Clamp Tie head design contains clamping rails to provide full circumferential compression around bundles.

    • Heat stabilized cable ties provide excellent resistance to high heat exposures.
    • Head design contains clamping rails to provide full circumferential compression around bundles.
    • Bent tail allows for quick insertion into head.
    Package size
    Add to watchlist
    Downloads e-Learning
    Application CTT is designed to secure pipes, hoses and gaiters where low pressures are being secured. These ties can be used in many different industries including automotive, white goods manufacturing, medical industry and construction.
    Brand Family CTT-Series
    Color Black (BK)
    Description The 360 degree compression ties are designed with underside clamping rails to allow for optimal surface contact and complete circumferential compression around the bundle. The bent tail design allows quick and simple installations by hand. For high-volume applications, tensioning tools are available to ensure consistent and safe installation.
    Min. Tensile Strength (imperial) 20lbs
    Min. Tensile Strength (metric) 90N
    PART DESCRIPTION CTT20R-PA66HS-BK
    Packaging Type pack
    Part No. CTT20R0HSC2
    Product family Cable Ties
    Product family Cable Ties, Products for wires and hoses
    Short Desc. Clamp Tie, 4" Long, 20lb Tensile Strength, PA66HS, Black, 100/pkg
    Type CTT20R
    UV Resistant No
    Cable Tie Closure plastic pawl
    Identification Plate Position none
    Length (imperial) 4.0"
    Length (metric) 101.6mm
    Max. Bundle Diameter (imperial) 0.51"
    Max. Bundle Diameter (metric) 13.0mm
    Min. Bundle Diameter (imperial) 0.06"
    Min. Bundle Diameter (metric) 1.6mm
    Releasable Closure No
    Thickness (imperial) 0.043"
    Thickness (metric) 1.1mm
    Width (imperial) 0.10"
    Width (metric) 2.5mm
    CE Certification Yes
    CSA Certified No
    Flammability UL 94 V-2
    Material PA66HS
    Material Polyamide 6.6 heat stabilized (PA66HS)
    Operating Temperature -40°F to +257°F (-40°C to +125°C)
    Prop65 Warning No
    REACH Conformity Yes
    ROHS compliant Yes
    UL File Number [Logo] E64139 [C_RU_US_62275_Type11]
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US) Yes
    UL Type Number 11
    Customs Number (Schedule B) 3926909988
    Harmonized Tariff Schedule Code 3926.90.9989
    Packaging 1 - Weight (kg) 0.0318kg
    Pkg. Qty. 100
    Pkg. Qty. 100Pieces
