Cable tie, 149.9x8.0mm, ⌀1.5-35.0mm, beige, 1000pcs.

Art.-No. 111-01542

| PAT100R-PAEK-BGE

|

PAEK material has double the tensile strength than nylon.

Package size

100 pcs.

1000 pcs.

Add to watchlist

Downloads

Base Data

Colour	Beige (BGE)
Material	Polyaryletherketone (PAEK)
Min.Tensile Strength	445N
PART DESCRIPTION	PAT100R-PAEK-BGE
Package Content	1000pcs.
Package Content packed in	pack
Type	PAT100R
UV-Stabilised	No

Product Dimensions

Bundle ⌀	1.5-35.0mm
Bundle ⌀ max.	35.0mm
Bundle ⌀ min.	1.5mm
Length (L)	149.9mm
Width (W)	8.0mm

Specifications

CE Certification	No
CSA Certified	No
Flammability	UL 94 V0
Operating Temperature	-55 °C to +200 °C
ROHS compliant	Yes
Specifications
UL Listed (US and Canada)	No
UL Listed (US)	No
UL Recognized (US and Canada)	No
UL Recognized (US)	No

Logistics and Packaging

Country of Origin	US
GTIN-13 / EAN	4031026767574
Packaging 1 - Qty	1000
Packaging 1 - Type	bag
Packaging 3 - Height (m)	0.20479m
Packaging 3 - Length (m)	0.5159375m
Packaging 3 - Type	carton
Packaging 3 - Volume (m³)	0.0332m³
Packaging 3 - Width (m)	0.314325m

More Information

ETIM 7.0 Key	EC000046
ETIM 8.0 Key	EC000046
ETIM 9.0 Key	EC000046
UNSPSC Key	39121703
