Fixing tie for screw fixation, inside serrated, Ø1.5-45.0mm, black, 1000pcs.
Art.-No. 113-00061 | T50MRX-PA66HS-BK Details

  • One-piece bundling and fixing tie
  • Quick and easy installation
Package size
Application This range of one piece cable ties have a built in mounting hole and once fastened around the cables the bundle can be simply secured to the panel with a screw or bolt. The tie is fitted to the panel first and then the cables can be added.
Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7SP, EVO7i
Colour Black (BK)
Fixation Method Screw Mount
Identification Plate Position none
Material Polyamide 6.6, heat stabilised (PA66HS)
Mounting Screw Type #1/4" (M6) Screw
Pack Cont. 1000pcs.
Package Content packed in bag
PART DESCRIPTION T50MRX-PA66HS-BK
Product Family M-Series
Product Group 1-piece fixing ties with mounting head for screws
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Variant Inside Serrated
Bundle Diameter max (metric) 45.0mm
Bundle ∅ 1.5-45.0mm
Bundle ∅ min. 1.5mm
for Hole ∅ (FH) 5.2 mm
Height (H) 6.0mm
Length (L) 203.2mm
Mechanical Strength 177.9N
Min.Tensile Strength 225N
Width (W) 4.7mm
CE Certification Yes
CSA Certified No
Flammability UL 94 V2
Operating Temperature -40 °C to +125 °C
Plenum Rating AH-2
Specifications
Specifications UL 62275
UL Listed (US and Canada) Yes
UL Recognized (US and Canada) Yes
UL-File Number E64139
UV-Stabilised (Yes/No) No
Country of Origin US
GTIN-13 / EAN 4031026687513
Packaging 3 - Height (m) 0.21589999999999998m
Packaging 3 - Length (m) 0.606425m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.052
Packaging 3 - Weight (kg) 9.66kg
Packaging 3 - Width (m) 0.396875m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
