Fixing tie for hole (oval), inside serrated, ⌀5.0-50.0mm, black, 3000pcs.
Art.-No. 133-01739 | T50RFT9x17LGSET-PA66HS/PA66HIRHSUV-BK

Friction tab inside the fir tree allows the tie to sit in mount without falling out prior to installation.
Fir tree provides low insertion effort yet demonstrates high extraction resistance.
Disc feature prevents rattling in high-vibration applications and protects against debris ingress.

Color	Black (BK)
Description	HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole. The mount can slide along the cable tie to adjust orientation as needed. Fir tree mounts are designed to provide a low insertion force and high extraction force. This mount is sold as an assembly with the cable tie.
Min. Tensile Strength (imperial)	50lbs
Min. Tensile Strength (metric)	225N
PART DESCRIPTION	T50RFT9x17LGSET-PA66HS/PA66HIRHSUV-BK
Packaging Type	carton
Part No.	133-01739
Product family	Fixing Ties
Product family	Fixing ties for holes
Short Desc.	2-Piece Cable Tie with Oval Fir Tree Mount, 9.0x17.0mm Mounting Hole Dia, PA66HS/PA66HIRHS, 3000/carton
Type	T50RFT9x17LGSET
UV Resistant	No

Cable Tie Closure	plastic pawl
Fixation Method	Fir Tree for oval holes
Height (imperial)	0.99"
Height (metric)	25.25mm
Height 2 (imperial)	0.65"
Height 2 (metric)	16.5mm
Identification Plate Position	none
Length (imperial)	1.00"
Length (metric)	25.5mm
Max. Bundle Diameter (imperial)	1.97"
Max. Bundle Diameter (metric)	50.0mm
Max. Hole Depth (imperial)	0.37"
Max. Hole Depth (metric)	9.5mm
Max. Mounting Hole Diameter (imperial)	0.67"
Max. Panel Thickness (imperial)	0.37"
Max. Panel Thickness (metric)	9.5mm
Min. Bundle Diameter (imperial)	0.2"
Min. Bundle Diameter (metric)	5.0mm
Min. Hole Depth (imperial)	0.02"
Min. Hole Depth (metric)	0.6mm
Min. Mounting Hole Diameter (imperial)	0.35"
Min. Panel Thickness (imperial)	0.02"
Min. Panel Thickness (metric)	0.6mm
Mounting Hole Diameter (imperial)	0.35 x 0.67 "
Mounting Hole Diameter (metric)	9.0 x 17.0 mm
Mounting Hole Shape	Oval
Panel Thickness (imperial)	0.02 - 0.37"
Panel Thickness (metric)	0.6 - 9.5mm
Releasable Closure	No
Width (imperial)	0.80"
Width (metric)	20.3mm

CE Certification	No
Material	PA66HS, PA66HIRHSUV
Material	Polyamide 6.6 heat stabilized (PA66HS), Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Operating Temperature	-40°F to +221°F (-40°C to +105°C)
Operating Temperature, 1000h	+320°F (+160°C)
Operating Temperature, 5000h	+257°F (+125°C)
Operating Temperature, 500h	+329°F (+165°C)
Prop65 Warning	No
REACH Conformity	Yes
ROHS compliant	Yes
UL Listed (US and Canada)	No
UL Listed (US)	No
UL Recognized (US and Canada)	No
UL Recognized (US)	No


Customs Number (Schedule B)	3926909988
Harmonized Tariff Schedule Code	3926.90.9989
Packaging 1 - Weight (kg)	7.200001kg
Pkg. Qty.	3000
Pkg. Qty.	3000Pieces
