29/03/2024

Fixing tie with pipe/tube holder, inside serrated, Ø5.5-6.8mm, black, 2000pcs.
Art.-No. 156-01812 | T50RMOC6SAD-SET-PA66HIRHSUV-BK Details

Cable ∅ max 50.0mm
Cable ∅ min 1.5mm
Colour Black (BK)
Fixation Method Omega Clip
Identification Plate Position none
Key product features removable, for multiple routing
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Pack Cont. 2000pcs.
Package Content packed in carton
PART DESCRIPTION T50RMOC6SAD-SET-PA66HIRHSUV-BK
Product Group 2-Piece Fixing Ties with Pipe Clip
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Variant Inside Serrated
Bundle Diameter max (metric) 6.8mm
Bundle Diameter Nom. (ND) 6.0 mm
Bundle ∅ 5.5-6.8mm
Bundle ∅ min. 5.5mm
Depth (D) 10.0mm
Height (H) 17.9mm
Length (L) 11.1mm
Length (L2) 11.5mm
Min.Tensile Strength 225N
Weight/Unit 0.006039kg
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +110 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised (Yes/No) Yes
Country of Origin MX
Customs Number 39269097
GTIN-13 / EAN 4031026592350
Packaging 1 - Qty 3000
Packaging 1 - Type bag
Packaging 1 - Weight (kg) 18.117001kg
Packaging 3 - Qty 3000
Packaging 3 - Type carton
Packaging 3 - Weight (kg) 18.117001kg
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121702
