Fixing tie, inside serrated, ⌀4.0-50.0mm, black, 1000Carton
Art.-No. 156-03335
| T50RUPBM9SET-PA66HIRHSUV-BK
|
Copied
| Colour | Black (BK) |
| Description | This button head mount includes a cable tie to secure cables and wire bundles to panels. Once placed through a panel hole, installers can insert the cable tie through the mount on the panel’s opposite side. The button head mount is designed to fit pre-stamped oval hole sizes 7x10 mm, 7x12 mm, 8.5x16 mm, 9x12 mm and 9x14 mm with zero insertion force. |
| Fixation Method | Button Head |
| Identification Plate Position | none |
| Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
| Mechanical Strength | 178N |
| Min.Tensile Strength | 225N |
| PART DESCRIPTION | T50RUPBM9SET-PA66HIRHSUV-BK |
| Package Content | 1000Carton |
| Package Content packed in | carton |
| Product Group | 2-piece fixing ties with button mount, for round holes |
| Releasable Closure (Yes/No) | No |
| Tie Closure | plastic pawl |
| Type | T50RUPBM9SET |
| UV-Stabilised | Yes |
| Bundle ⌀ | 4.0-50.0mm |
| Bundle ⌀ max. | 50.0mm |
| Bundle ⌀ min. | 4.0mm |
| Cable Tie Head Length (metric) | 7.3mm |
| Cable Tie Head Width (metric) | 7.6mm |
| Height (H) | 13.40mm |
| Length (L) | 203.2mm |
| Panel Thickness | 3.0mm |
| Strap Width max. (G) | 0.30" |
| Thickness (T) | 1.2mm |
| Width (W) | 17.0mm |
| for Hole ⌀ (FH) | 7.0 x 10.0 mm, 9.0 x 12.0 mm, 9.0 x 14.0 mm, 8.5 x 16.0 mm, 8.5 mm, 9.0 mm |
| for Panel Thickness min - max | - 3 |
