01/10/2025

Fixing tie with pipe/tube holder, ⌀14.0-18.3mm, black, 100pcs.
Art.-No. 156-04242 | T50SMVCMOC16M-PA66HIRHSUV-BK |

Copied
Independent rotation allows for adjustable routing orientation.

    Package size
    Add to watchlist
    Downloads
    Cable ⌀ max 50.0mm
    Cable ⌀ min 2.0mm
    Colour Black (BK)
    Fixation Method Omega Clip
    Identification Plate Position none
    Key product features lockable, rotatable
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Min.Tensile Strength 225N
    PART DESCRIPTION T50SMVCMOC16M-PA66HIRHSUV-BK
    Package Content 100pcs.
    Package Content packed in pack
    Product Group 2-piece fixing ties with pipe clip
    Type T50SMVCMOC16M
    UV-Stabilised Yes
    Bundle ⌀ 14.0-18.3mm
    Bundle ⌀ max. 18.3mm
    Bundle ⌀ min. 14.0mm
    Depth (D) 12.0mm
    Height (H) 37.5mm
    Length (L) 25.7mm
    Length (L2) 19.2mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +110 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin MX
    GTIN-13 / EAN 4031026695884
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 3 - Height (m) 0.20479m
    Packaging 3 - Length (m) 0.5159375m
    Packaging 3 - Qty 1000
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0332m³
    Packaging 3 - Weight (kg) 2.1kg
    Packaging 3 - Width (m) 0.314325m
    Packaging 4 - Qty 40000
    Packaging 4 - Type pallet
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121702
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
    Art.-No.: 156-04242 Contact
    Base Data Product Dimensions Specifications Logistics and Packaging Downloads
