Fixing tie for stud, ⌀9.5-105.0mm, black, 800pcs.
Art.-No. 157-00462
| WSR8MMB-PA66HIRHSUV-BK
Copied
- Provides separation between bundles to prevent chafing and abrasion.
- High tensile strength of 150 lb suits heavy duty applications.
- Straps are releasable for increased serviceability.
More products in this product group:
| Application | Primarily designed for use in the automotive industry, these parts can be used in a wide variety of applications where weld studs or ISO bolts are used and cables need to be bundled and secured. |
| Color | Black (BK) |
| Description | These cable ties attach with a screw or bolt to an existing hole, or secure to a stud with a nut. They provide an attachment point for securing and routing a single bundle. The mounts provide the highest level of fastening for critical cable security. |
| Min. Tensile Strength (imperial) | 120lbs |
| Min. Tensile Strength (metric) | 535N |
| PART DESCRIPTION | WSR8MMB-PA66HIRHSUV-BK |
| Packaging Type | carton |
| Part No. | 157-00462 |
| Product family | 1-Piece Tie Assemblies |
| Product family | Products to use on studs |
| Short Desc. | 1-Piece Cable Tie with Screw Mount, 16.1" Long, M8 Hole, 4.1" Max Bundle Dia, PA66HIRHSUV, Black, 800/ctn |
| Type | WSR8MMB |
| UV Resistant | Yes |
| Cable Tie Closure | plastic pawl |
| Fixation Method | Weld Stud Fixing |
| Height (imperial) | 0.19" |
| Height (metric) | 4.9mm |
| Identification Plate Position | none |
| Length (imperial) | 16.1" |
| Length (metric) | 410.0mm |
| Max. Bundle Diameter (imperial) | 4.13" |
| Max. Bundle Diameter (metric) | 105.0mm |
| Min. Bundle Diameter (imperial) | 0.37" |
| Min. Bundle Diameter (metric) | 9.5mm |
| Mounting Hole Diameter (imperial) | 0.33 " |
| Mounting Hole Diameter (metric) | 8.4 mm |
| Releasable Closure | No |
| Thickness (imperial) | 0.06" |
| Thickness (metric) | 1.4mm |
| Width (imperial) | 0.5" |
| Width (metric) | 12.7mm |
Download
| CE Certification | No |
| CSA Certified | No |
| Material | PA66HIRHSUV |
| Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV) |
| Operating Temperature | -40°F to +221°F (-40°C to +105°C) |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
