Fixing tie, inside serrated, ⌀9.4-57.15mm, black, 600Carton
Art.-No. 156-03336 | WSSDFTM8WSSDSET-PA66HIRHS-BK |

Copied
These fir tree fixings can also be used in threaded, blind holes.

    Package size
    Add to watchlist
    Downloads
    Colour Black (BK)
    Fixation Method Fir tree for round holes
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    Min.Tensile Strength 533N
    PART DESCRIPTION WSSDFTM8WSSDSET-PA66HIRHS-BK
    Package Content 600Carton
    Package Content packed in carton
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type WSSDFTM8WSSDSET
    UV-Stabilised No
    Variant Inside Serrated
    Bundle ⌀ 9.4-57.15mm
    Bundle ⌀ max. 57.15mm
    Bundle ⌀ min. 9.4mm
    Height (H) 22.77mm
    Length (L) 231.14mm
    Panel Thickness max. 0.6 - 6.0mm
    Width (W) 22.6mm
    for Hole ⌀ (FH) 6.1 - 7.0 mm, M8 Threaded
    for Panel Thickness min - max 0.6 - 6 mm
    for Panel Thickness min - max 0 - 0.2 "
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin US
    GTIN-13 / EAN 4031026766669
    Packaging 1 - Type bag
    Packaging 3 - Height (m) 0.20955m
    Packaging 3 - Length (m) 0.5175m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0344m³
    Packaging 3 - Width (m) 0.3175m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121702
