22/02/2026

Fixing tie for hole (round), ⌀5.0-55.0mm, black, 250pcs.
Art.-No. 156-03092 | X120SFT13-PA66HS/PA66HIRHS-BK

Copied

    • Friction tab inside the fir tree allows the tie to sit in mount without falling out prior to installation.
    • Fir tree provides low insertion effort yet demonstrates high extraction resistance.
    • Disc feature prevents rattling in high-vibration applications and protects against debris ingress.
    Add to watchlist
    Downloads e-Learning
    Color Black (BK)
    Description HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole. The mount can slide along the cable tie to adjust orientation as needed. Fir tree mounts are designed to provide a low insertion force and high extraction force. This mount is sold as an assembly with the cable tie.
    Min. Tensile Strength (metric) 535N
    PART DESCRIPTION X120SFT13-PA66HS/PA66HIRHS-BK
    Packaging Type bag
    Part No. 156-03092
    Product family 2-Piece Tie Assemblies
    Type X120SFT13
    Fixation Method Fir Tree
    Identification Plate Position none
    Length (metric) 225.0mm
    Max. Bundle Diameter (metric) 55.0mm
    Max. Panel Thickness (metric) 10.0mm
    Min. Bundle Diameter (metric) 5.0mm
    Min. Panel Thickness (metric) 0.7mm
    Mounting Hole Diameter (metric) 12.8 - 13.2 mm
    Panel Thickness (metric) 0.7-10.0mm
    Width (metric) 7.7mm
    Material PA66HS, PA66HIRHS
    Material Polyamide 6.6 heat stabilized (PA66HS), Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
    ROHS compliant Yes
    Pkg. Qty. 250Pieces
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
    Art.-No.: 156-03092 Contact
