Bundling clip, L=50.8mm, SO=26.0mm, black, 1500Carton
Art.-No. 133-02797 | BC51C-PA66HIRHS-BK

Copied
Application Bundling clips are designed to provide simple and easy methods of securing cable bundles, hoses, or pipes. They are fastened onto the tape bar using bundle or cable ties. The different fixing orientations allow tape clips to be used with a wide range of panel thicknesses and hole diameters. Standard bundling clips are available as well as standoff and stud mount versions.
Colour Black (BK)
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION BC51C-PA66HIRHS-BK
Pack Cont. 1500Carton
Package Content packed in carton
Type BC51C
⌀ D 1.28"
Bundle ⌀ 32.4-32.6mm
Bundle ⌀ max. 32.6mm
Bundle ⌀ min. 32.4mm
Bundling Bar Length 2.0"
Bundling Bar Length 50.8mm
Diameter (D) 32.5mm
Height (H) 50.3mm
Length (L) 50.8mm
Offset Length 26.0mm
UV-Stabilised No
Width (W) 8.7mm
CE Certification No
CSA Certified No
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
Country of Origin MX
GTIN-13 / EAN 4031026580722
Packaging 3 - Height (m) 0.352424999999999m
Packaging 3 - Length (m) 0.5715m
Packaging 3 - Qty 1500
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0703
Packaging 3 - Weight (kg) 6.1kg
Packaging 3 - Width (m) 0.34925m
Packaging 4 - Qty 27000
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 39121702
