Bundling clip for hole (round), L=56.0mm, black, 2500pcs.
Art.-No. 151-03473 | BC56FT6.5-PA66HIRHSUV-BK

Copied
Application Bundling clips are designed to provide simple and easy methods of securing cable bundles, hoses, or pipes. They are fastened onto the tape bar using bundle or cable ties. The different fixing orientations allow tape clips to be used with a wide range of panel thicknesses and hole diameters. Standard bundling clips are available as well as standoff and stud mount versions.
Colour Black (BK)
Fixation Method Fir tree for round holes
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION BC56FT6.5-PA66HIRHSUV-BK
Pack Cont. 2500pcs.
Package Content packed in pack
Type BC56FT6.5
Bundling Bar Length 2.20"
Bundling Bar Length 56.0mm
Height (H) 19.7mm
Height (H2) 16.1mm
Hole Depth 0.60mm
Hole Depth 6.0mm
Length (L) 56.0mm
Panel Thickness max. 0.6 - 6.0mm
UV-Stabilised Yes
Weight/Unit 0.01kg
Width (W) 8.0mm
for Hole ⌀ (FH) 6.1 - 7.0 mm
for Panel Thickness min - max 0.6 - 6 mm
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
Country of Origin MX
Customs Number 39269097
GTIN-13 / EAN 4031026666556
Packaging 1 - Type bag
Packaging 3 - Height (m) 0.20479m
Packaging 3 - Length (m) 0.5159375m
Packaging 3 - Qty 2500
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0332
Packaging 3 - Weight (kg) 25.0kg
Packaging 3 - Width (m) 0.314325m
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 39121702
