Connector clip for connector/for hole (round), EWCAP-005-11, black, 1500pcs.
Art.-No. 151-03961 | CC11FT6.5FT5-2-PA66HIRHS-BK

HellermannTyton connector clips provide a simple and easy method for mounting connectors to a mounting surface in a variety of applications.
Detailed designs include anti-rattle disc features, anti-rotation oval fir trees, and clamps for mounting on edges.
HellermannTyton offers an assortment of connector clips that are available for a variety of connector slot designs found on most of the largest global connector manufacturers.

Application	The connector clips used here have been designed for electronic cables and cable sets used in the automotive industry.
Brand Family	Connector-Series
Color	Black (BK)
Key product features	ergonomic design
PART DESCRIPTION	CC11FT6.5FT5-2-PA66HIRHS-BK
Part No.	151-03961
Product family	Connector Clips
Product family	Connector Accessory
Type	CC11FT6.5FT5-2

Fixation Method	Fir Tree
Height (metric)	19.4mm
Height 2 (metric)	11.5mm
Length (metric)	30.5mm
Length 2 (metric)	32.8mm
Max. Panel Thickness (metric)	5.5mm
Min. Panel Thickness (metric)	0.6mm
Mounting Hole Diameter (metric)	6.1 - 6.9 mm, 4.8 - 5.2 mm
Panel Thickness (metric)	0.6 - 5.5mm
Width (metric)	18.0mm
Width 2 (metric)	10.85mm
Width 3 (metric)	5.75mm

Material	PA66HIRHS
Material	Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
REACH Conformity	Yes
ROHS compliant	Yes
