Connector clip, black, 500pcs.
Art.-No. 151-03328 | CC33SFT6.5X13-MD-PA66HIRHS/CR-BK |

Copied

    Add to watchlist
    Downloads
    Application The Connector Clips used here have been designed for electronic cables and cable sets used in the automotive industry. These parts are related to a connector and then secured to a surface depending on the requirement
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS), Chloroprene Rubber (CR)
    PART DESCRIPTION CC33SFT6.5X13-MD-PA66HIRHS/CR-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Type CC33SFT6.5X13-MD
    Height (H) 18.6mm
    Length (L) 28.0mm
    Width (W) 19.0mm
    for Hole ⌀ (FH) 6.5 x 13.0 mm
    for Panel Thickness min - max 2 - 2 mm
    Country of Origin CN
    GTIN-13 / EAN 4031026651422
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 31162305
