20/10/2025

Connector clip for connector, EWCAP-005-11, black, 5000pcs.
Art.-No. 151-03772 | DBLEFAKRA-PA66HIRHSUV-BK |

Copied
USCAR7 bracket easily routes two parallel connectors.

    Add to watchlist
    Downloads
    Application The Connector Clips used here have been designed for electronic cables and cable sets used in the automotive industry. These parts are related to a connector and then secured to a surface depending on the requirement
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION DBLEFAKRA-PA66HIRHSUV-BK
    Pack Cont. 5000pcs.
    Package Content packed in carton
    Type DBLEFAKRA
    Type of connection USCAR7
    Variant 11 mm USCAR Connector Clip
    Height (H) 8.7mm
    Length (L) 36.42mm
    Weight/Unit 0.002kg
    Width (W) 24.2mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +90 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    UV-Stabilised Yes
    Country of Origin MX
    Customs Number 39269097
    GTIN-13 / EAN 4031026690711
    Packaging 3 - Height (m) 0.216m
    Packaging 3 - Length (m) 0.60801m
    Packaging 3 - Qty 5000
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0521m³
    Packaging 3 - Weight (kg) 10.765kg
    Packaging 3 - Width (m) 0.396875m
    Packaging 4 - Height (m) 1.219m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 75000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.17m³
    Packaging 4 - Weight (kg) 182.475kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 31162305
