Fixing elements for use with Paste adhesive
Art.-No. 151-04330 | IRCCPMB6CC-PA66HIRHSUV/PA66/6HIRHS-BK

Copied
  • One-piece ratchet closure allows for easy installation during pre- or final assembly
  • Easy release feature simplifies quick adjustments and maintenance
  • Impact modified, heat and UV stabilized PA66 provides long-term durability, indoors and out
  • Can even be installed onto uneven surfaces
  • Use with paste adhesive on the base to ensure a strong bond with the mounting surface
Show more
Application The In-line Ratchet P-Clamp family offers versatility when managing wires, cables and hoses. The robust design and durable materials make it ideal for heavy duty applications, both indoors and out. The adjustable clamp can be closed by hand to the desired diameter. The release feature allows easy and nondestructive removal of cables simply by using a flat-head screwdriver. In this way, the clamp can be reused or serviced without removing it from the mounting surface.
Colour Black (BK)
Fixation Method Pasting / Stick
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Polyamide 6.6/6, high impact modified, heat stabilised (PA66/6HIRHS)
PART DESCRIPTION IRCCPMB6CC-PA66HIRHSUV/PA66/6HIRHS-BK
Pack Cont. 100pcs.
Package Content packed in bag
Product Family In-Line Ratchet P-Clamp
Product Group Fixing elements for use with Paste adhesive
Type IRCCPMB6CC
UV-Stabilised Yes
Weight/Unit 0.029436kg
Bundle ⌀ 19.4-36.0mm
Bundle ⌀ max. 36.0mm
Bundle ⌀ min. 19.4mm
Height (H) 42.7mm
Length (L) 34.8mm
Width (W) 44.2mm
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Reusable (Yes/No) Yes
Specifications
Country of Origin PL
Customs Number 39269097
GTIN-13 / EAN 4031026752150
Packaging 1 - Height (m) 0.15m
Packaging 1 - Length (m) 0.545m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.03801375
Packaging 1 - Weight (kg) 2.987197kg
Packaging 1 - Width (m) 0.465m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 300
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 9.781591kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 3600
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 138.394kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 31162305
