Cable clip, Dmin=19.4mm, Dmax=36.0mm
Art.-No. 156-03003
| IRCCSTRUT-PA66HIRHSUV-BK
Copied
- Clamp and mount combination means no extra hardware is needed, for time-saving, toolless, one-handed installation.
- Three size ranges handle diameters from 0.5" to 2", reducing part inventory.
- Clamp saddle provides additional attachment option using a cable tie.
- Impact modified, heat and UV stabilized PA66 provides long-term durability, indoors and out.
More products in this product group:
| Application | The Inline Ratchet Clamp family is a perfect fit when facing space constraints or where offset mounting options are not ideal. Easily twists onto existing threaded rods, eliminating the need for additional hardware. The robust design and durable materials make it ideal for heavy duty applications, both in- and outdoors. The one-piece adjustable clamp can be closed by hand to the desired diameter. The release feature provides easy and nondestructive removal of cables simply by using a flat-head screwdriver. This allows the clamp to be reused without removing or replacing any bolts or screws. |
| Brand Family | Ratchet Clamps |
| Color | Black (BK) |
| Description | The Quick2Clamp offers ultra-fast installation and versatility for managing conduit, tubing and cables. The built-in strut mount attaches with a simple twist. The one-piece design makes it simple to install without tools. Robust, adjustable clamp closes by hand to the desired diameter. A release feature allows easy and nondestructive maintenance simply by using a flat-head screwdriver. In this way, the clamp can be reused or serviced without removing it from the strut. |
| Max. Static Load (imperial) | 70lbs |
| PART DESCRIPTION | IRCCSTRUT-PA66HIRHSUV-BK |
| Packaging Type | pack |
| Part No. | 156-03003 |
| Product family | Strut Mount |
| Product family | Products for wires and hoses, products for strut profile |
| Short Desc. | Quick2Clamp, Ratchet, 0.76" - 1.42" Bundle Dia, 1-5/8" Strut Attachment, PA66HIRHSUV, Black, 25/bg |
| Type | IRCCSTRUT |
| UV Resistant | Yes |
| Fixation Method | 1-5/8 " strut attachment |
| Height (imperial) | 2.04" |
| Height (metric) | 51.8mm |
| Length (imperial) | 4.56" |
| Length (metric) | 115.9mm |
| Max. Bundle Diameter (imperial) | 1.42" |
| Max. Bundle Diameter (metric) | 36.0mm |
| Maximum Static Load (N) | 311N |
| Min. Bundle Diameter (imperial) | 0.76" |
| Min. Bundle Diameter (metric) | 19.4mm |
| Width (imperial) | 1.37" |
| Width (metric) | 34.81mm |
Download
| CE Certification | No |
| CSA Certified | No |
| Halogen Free | Yes |
| Material | PA66HIRHSUV |
| Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV) |
| Operating Temperature | -40°F to +221°F (-40°C to +105°C) |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| Reusable (Yes/No) | Yes |
| UL File Number [Logo] | E523406 [UL] |
| UL Listed (US and Canada) | No |
| UL Listed (US) | Yes |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
