P-clamp closed, Ø4.0 mm, Dmin=17.4mm, Dmax=20.0mm, black, 200pcs.
Art.-No. 221-10110 | NX11-PA66-BK |  Details

    • Manufactured from Polyamide
    • Good temperature resistance and high strength
    • Wide range of sizes for every application
    • Can be used without cable ties
    Package size
    Add to watchlist
    Downloads
    Application For permanent or semi-permanent cable fixings this range of plastic P-Clamps can be used in many industries. Their light weight makes them particularly suitable for use in areas such as aircraft and aerospace where minimising weight, but retaining a strong fixing, is vitally important.
    Colour Black (BK)
    Fixation Method screw-hole
    Material Polyamide 6.6 (PA66)
    Pack Cont. 200pcs.
    Package Content packed in pcs.
    PART DESCRIPTION NX11-PA66-BK
    Product Family HP-Series
    Product Group Plastic P-Clamps
    Variant Closed
    Bundle Diameter max (metric) 20.0mm
    Bundle ∅ 17.4-20.0mm
    Bundle ∅ min. 17.4mm
    for Hole ∅ (FH) 4.0 mm
    Wall (WT) 1.3mm
    Width (W) 12.6mm
    Nato number 5340-12-183-1679
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 5022660313325
    Packaging 1 - Qty 200
    Packaging 1 - Weight (kg) 0.2200kg
    Packaging 3 - Height (m) 0.192m
    Packaging 3 - Length (m) 0.586m
    Packaging 3 - Qty 4000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0439m³
    Packaging 3 - Weight (kg) 4.70kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.11m
    Packaging 4 - Length (m) 1.15m
    Packaging 4 - Qty 72000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 0.932m³
    Packaging 4 - Weight (kg) 104.0kg
    Packaging 4 - Width (m) 0.73m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
