Cable clip
Art.-No. 133-03187 | PC6.5X2-PA66HIRHSUV-BK

Copied
Dual pipe clip secures two routings together while keeping them separated, to prevent chafing or heat transfer.
PC6_5X2
These pipe clips are a good soloution if lines need to be routed in parallel.

    • Dual pipe clip secures two routings together while keeping them separated, to prevent chafing or heat transfer
    • Inverted retaining legs and narrow opening prevent inadvertent disengagement of pipe
    • Controlled flex and angled entry promote easy pipe installation
    • For use with routings of the following size:
    • 2 x 65-70 mm
    Package size
    Add to watchlist
    Downloads
    Application Designed for the parallel routing of multiple tubes and harnesses. Simple manual assembly into the clip for a firm and secure hold of the bundle. Prevents easily the twisting of tubes or harnesses.
    Brand Family PC-Series
    Color Black (BK)
    Description This clip features a modular design that can be used individually or lined together to secure multiple pipes or hoses.
    PART DESCRIPTION PC6.5X2-PA66HIRHSUV-BK
    Packaging Type pack
    Part No. 133-03187
    Product family Products for wires and hoses, Products for parallel/multiple routing
    Short Desc. Tube and Pipe Clip, 2x 6.5-7.0mm diameter, PA66HIRHSUV, Black, 3,000/ctn
    Type PC6.5X2
    UV Resistant Yes
    Height (imperial) 0.49"
    Height (metric) 12.0mm
    Length (imperial) 1.03"
    Length (metric) 25.25mm
    Nominal Diameter (metric) 6.35mm
    Width (imperial) 0.4"
    Width (metric) 10.16mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Material PA66HIRHSUV
    Material Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
    Operating Temperature -40°F to +221°F (-40°C to +105°C)
    Prop65 Warning No
    REACH Conformity Yes
    ROHS compliant Yes
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Customs Number (Schedule B) 3926909988
    Harmonized Tariff Schedule Code 3926.90.9989
    Pkg. Qty. 3000Pieces
    Pkg. Qty. 3000
