Cable clip, ⌀8.0 mm, Dmin=6.5mm, Dmax=7.0mm
Art.-No. 151-03363 | PC6.5x2FT8.0-PA66HIRHSUV-BK

Copied

    Add to watchlist
    Downloads
    Brand Family PC-Series
    Color Black (BK)
    PART DESCRIPTION PC6.5x2FT8.0-PA66HIRHSUV-BK
    Packaging Type bag
    Part No. 151-03363
    Product family Products for wires and hoses
    Type PC6.5x2FT8.0
    UV Resistant Yes
    Fixation Method Fir Tree
    Height (imperial) 1.06"
    Height (metric) 26.9mm
    Length (imperial) 1.17"
    Length (metric) 29.6mm
    Max. Bundle Diameter (imperial) 0.28"
    Max. Bundle Diameter (metric) 7.0mm
    Max. Panel Thickness (imperial) 0.22"
    Max. Panel Thickness (metric) 5.5mm
    Min. Bundle Diameter (imperial) 0.26"
    Min. Bundle Diameter (metric) 6.5mm
    Min. Panel Thickness (imperial) 0.02"
    Min. Panel Thickness (metric) 0.6mm
    Mounting Hole Diameter (imperial) 0.31 "
    Mounting Hole Diameter (metric) 8.0 mm
    Width (imperial) 0.39"
    Width (metric) 10.0mm
    Material PA66HIRHSUV
    Material Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
    Pkg. Qty. 1000Pieces
    Pkg. Qty. 1000
