Bundling clip for hole (oval), L=42.0mm, SO=18.0mm, black
Art.-No. 133-00824 | SOC25FT63x100-PA66HIRHS-BK |

Copied

    • Effortless, tool-free installation – can be mounted easily by hand without the need for tools
    • Flexible attachment options – compatible with both cable ties and adhesive tape
    • Oval base geometry – ensures defined cable routing and provides reliable anti-twist protection for secure positioning
    Add to watchlist
    Downloads
    Application These bundling clips are mainly used in the automotive industry, particularly for the assembly of cable harnesses. They offer a simple and user-friendly method for fastening cables, hoses and pipes.
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION SOC25FT63x100-PA66HIRHS-BK
    Package Content packed in bag
    Product Family for oval holes
    Product Group Bundling clips with fir tree
    Type SOC25FT63x100
    Bundling Bar Length 42.0mm
    Fixing Hole Shape Oval
    Length (L) 42.0mm
    Length (L2) 18.0mm
    Offset Length 18.0mm
    Panel Thickness max. 0.6-2.5mm
    for Hole ⌀ (FH) 6.3 x 10.0 mm
    for Panel Thickness min - max 0.6 - 2.5 mm
    Country of Origin CN
    GTIN-13 / EAN 4031026435053
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
