Bundling clip for stud, L=55.0mm, black, 500pcs.
Art.-No. 151-00484 | TCSB5CYCC-PA66HIRHS-BK

HellermannTyton connector clips provide a simple and easy method for mounting connectors to a mounting surface in a variety of applications.
Detailed designs include anti-rattle disc features, anti-rotation oval fir trees, and clamps for mounting on edges.
HellermannTyton offers an assortment of connector clips that are available for a variety of connector slot designs found on most of the largest global connector manufacturers.

More products in this product group:

Application	Bundling clips are designed to provide simple and easy methods of securing cable bundles, hoses, or pipes. They are fastened onto the tape bar using bundle or cable ties. The different fixing orientations allow tape clips to be used with a wide range of panel thicknesses and hole diameters. Standard bundling clips are available as well as standoff and stud mount versions.
Color	Black (BK)
Description	HellermannTyton connector clips, for oval holes, are mounted simply by pushing them onto the corresponding clip. The clips provide a wide range of mounting options with anti-rattle and anti-rotation features. The fir tree locks into place when inserted into the hole palpably and ensures a secure fixing at all times.
PART DESCRIPTION	TCSB5CYCC-PA66HIRHS-BK
Packaging Type	bag
Part No.	151-00484
Product family	Bundling Clips, Connector Clips, Stud Mounts
Product family	Bundling Clips, Connector Accessory, Products to use on studs
Short Desc.	Connector Clip, 2.3" Long, PA66HIRHS, Black, 500/pkg
Type	TCSB5CYCC

Flammability	UL 94 HB
Material	PA66HIRHS
Material	Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
Operating Temperature	-40°F to +221°F (-40°C to +105°C)
REACH Conformity	Yes
ROHS compliant	Yes
