Connector clip for hole (oval)/for connector, black, 1000pcs.
Art.-No. 151-00180
| YCCFT62x122-PA66HIRHS-BK
Copied
- HellermannTyton Connector Clips provide a single method to mount connectors to various surfaces in a variety of applications.
- Highly engineered designs feature anti-rattle discs, anti-rotation oval fir trees and clamps for mounting on edges.
- An assortment of Connector Cips is available to fit the variety of connector slot designs made by most of the largest global connector manufacturers.
| Application | The connector mounts used here are intended for cables and cable sets in the automotive industry |
| Brand Family | CC-Series |
| Color | Black (BK) |
| Description | Connector Clips feature various attachment point configurations to accommodate the many connectors on the market. They are first mated with a connector on a wire harness or cable assembly, then secured to a surface using the integrated mount. With so many configurations available, attachment surfaces can be a hole, edge, stud or even another harness assembly. |
| Key product features | ergonomic design |
| PART DESCRIPTION | YCCFT62x122-PA66HIRHS-BK |
| Packaging Type | pack |
| Part No. | 151-00180 |
| Product family | Connector Clips |
| Product family | Connector Accessory |
| Short Desc. | Connector Clip with Oval Fir Tree, 0.6-6.0 mm Panel Thick, 6.2x12.2 mm Hole Dia, PA66HIRHS, Black, 1000/pkg |
| Type | YCCFT62x122 |
| UV Resistant | No |
| Fixation Method | Fir Tree for oval holes |
| Height (imperial) | 0.71" |
| Height (metric) | 18.0mm |
| Length (imperial) | 0.83" |
| Length (metric) | 21.08mm |
| Max. Mounting Hole Diameter (imperial) | 0.24" |
| Max. Panel Thickness (imperial) | 0.24" |
| Max. Panel Thickness (metric) | 6.0mm |
| Min. Mounting Hole Diameter (imperial) | 0.24" |
| Min. Panel Thickness (imperial) | 0.02" |
| Min. Panel Thickness (metric) | 0.6mm |
| Mounting Hole Diameter (imperial) | 0.24 x 0.48 " |
| Mounting Hole Diameter (metric) | 6.2 x 12.2 mm |
| Mounting Hole Shape | Oval |
| Panel Thickness (imperial) | 0.02 - 0.24" |
| Panel Thickness (metric) | 0.6 - 6.0mm |
| Width (imperial) | 0.63" |
| Width (metric) | 16.0mm |
