Accessory, HelaGuard®, black, 10pcs. (AFCP0380)
Art.-No. 166-90374 | AFCP0380-PA66-BK

Copied
Conduit clips feature an integrated flip open lid for quick and easy assembly.

    • Integrated flip open lid for quick and easy assembly.
    • Smooth inner surface holds tubing from slipping.
    • Easy access mounting hole reduces installation time.
    • Quick release for easy future access.
    Add to watchlist
    Downloads
    Brand Family HelaGuard®
    Color Black (BK)
    Description Conduit Clips clamp onto corrugated conduits and tubing to secure. Nylon material resists corrosion and chemicals. Can also be used on C-shaped DIN rails.
    PART DESCRIPTION AFCP0380-PA66-BK
    Packaging Type pack
    Part No. 166-90374
    Short Desc. HelaGuard® AFCP Smooth Tubing Clip,0.38" Dia, PA66, Black, 10/pkg
    Type AFCP0380
    UV Resistant No
    Height (imperial) 1.18"
    Height (metric) 30mm
    Length (imperial) 1.02"
    Length (metric) 26mm
    Mounting Hole Diameter (imperial) 0.24 "
    Mounting Hole Diameter (metric) 6.0 mm
    Nominal Diameter (imperial) 0.38"
    Nominal Diameter (metric) 16mm
    Trade Size 3/8 "
    Width (imperial) 0.59"
    Width (metric) 15mm
    Flammability UL 94 V-2
    Material PA66
    Material Polyamide 6.6 (PA66)
    Operating Temperature -58°F to +275°F (-50°C to +135°C)
    Pkg. Qty. 10Pieces
    Pkg. Qty. 10
    Cable protection conduits Cable protection conduits

    Cable Protection Conduits

    No cable can meet the demands posed today in terms of abrasion resistance, tensile strength and form consistency or impact resistance without having appropriate cable protection. Cable protection tubes...
