Accessory, HelaGuard, black, 10pcs. (ALPA0380)
Art.-No. 166-90018 | ALPA0380-PA66-BK |

Copied
HelaGuard ALPA PA66 Locknuts.

    Add to watchlist
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION ALPA0380-PA66-BK
    Package Content 10pcs.
    Package Content packed in pack
    Type ALPA0380
    UV-Stabilised No
    Variant Locknut
    Fits Conduit Size (Metric) 16mm
    Nominal ⌀ 0.38"
    Nominal ⌀ 16mm
    Thickness (T) 6.7mm
    Wrenching Flat Size (Imperial) 1.06"
    Wrenching Flat Size (Metric) 26.9mm
    CE Certification No
    CSA Certified No
    Halogen-free Yes
    Operating Temperature -50 °C to +135 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin GB
    GTIN-13 / EAN 4031026461533
    Packaging 1 - Qty 10
    Packaging 1 - Type pack
    UNSPSC Key 39131708
    Cable protection conduits Cable protection conduits

    Cable Protection Conduits

    No cable can meet the demands posed today in terms of abrasion resistance, tensile strength and form consistency or impact resistance without having appropriate cable protection. Cable protection tubes...
