Accessory, HelaGuard®, black, 10pcs. (PAEC1250)
Art.-No. 166-90188
| PAEC1250-PA66-BK
Copied
- Snaps over end of conduit when not terminated with fitting to provide smooth entry point and prevent damage to cables.
- Easy to install; reduces installation time.
| Brand Family | HelaGuard® |
| Color | Black (BK) |
| Description | Nylon cap snaps over un-terminated conduit ends to prevent damage to wires caused by rubbing against sharp conduit edges. For use with HelaGuard corrugated conduits. |
| PART DESCRIPTION | PAEC1250-PA66-BK |
| Packaging Type | pack |
| Part No. | 166-90188 |
| Short Desc. | HelaGuard® PAEC Conduit End Cap, 1.25" Dia, PA66, Black, 10/pkg |
| Type | PAEC1250 |
| UV Resistant | No |
| Bore Diameter (metric) | 32.0 |
| Bore Hole Diameter (imperial) | 1.26" |
| Fits Conduit Size | 1-1/4 " |
| Fits Conduit Size (metric) | 42mm |
| Height (imperial) | 0.94" |
| Height (metric) | 24mm |
| Max. Bundle Diameter (imperial) | 0" |
| Min. Bundle Diameter (imperial) | 0" |
| Nominal Diameter (imperial) | 1.25" |
| Nominal Diameter (metric) | 42mm |
| Trade Size | 1-1/4 " |
| Width (imperial) | 1.78" |
| Width (metric) | 45.2mm |
Download
| CE Certification | No |
| CSA Certified | No |
| Halogen Free | Yes |
| Material | PA66 |
| Material | Polyamide 6.6 (PA66) |
| Operating Temperature | -58°F to +275°F (-50°C to +135°C) |
| Prop65 Warning | No |
| REACH Conformity | No |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
