10/11/2025

Roof pass-through double entry, L=160mm, 1pc.
Art.-No. 169-00300 | Roof-Pass-Through-PPW-BK |

Copied

    • Fits UV-stabilized protective conduit tubing FCTUV16
    • Rated IP44 with pre-mounted gasket/sealing
    • Cover plug when only one entry is needed
    • Fits under roof tiles
    • UV-stabilized Polypropylene with lower CO2 footprint
    • Supplied with cable ties for strain relief
    Add to watchlist
    Downloads
    Application The roof pass-through, RPT, from HellermannTyton with double entries allows tubing and cables through the roof while protecting and sealing against water ingress. It has an IP44 rating and is made of environmentally friendly and UV-stabilized Polypropylene. It comes complete with pre-assembled gasket, cable ties and plug when one entry is sufficient. Developed to fit HellermannTyton's UV-stabilized protective conduit tubing FCTUV16 in both slit and unslit executions.
    Colour Black (BK)
    Material Polypropylene, UV-resistant (PPW)
    PART DESCRIPTION Roof-Pass-Through-PPW-BK
    Package Content 1pc.
    Package Content packed in box
    Type Roof-Pass-Through
    Variant Accessories
    Weight/Unit 0.058kg
    Height (H) 40mm
    Inside ⌀ (ID) 16.5mm
    Length (L) 160mm
    NW ⌀ 16.5mm
    Nominal ⌀ 5/8"
    Nominal ⌀ 16.5mm
    Outside ⌀ (OD) 20.7mm
    Outside ⌀ (OD2) 20.5mm
    Width (W) 65mm
    Operating Temperature -40 °C to +80 °C
    ROHS compliant Yes
    Specifications
    Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability.<br/>ReSource highlights HellermannTyton products that are made from recycled waste or from virgin materials with relatively lower carbon emissions. Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability.
    ReSource highlights HellermannTyton products that are made from recycled waste or from virgin materials with relatively lower carbon emissions.
    Country of Origin SE
    Customs Number 3917400099
    GTIN-13 / EAN 4031026760681
    Packaging 2 - Height (m) 0.17m
    Packaging 2 - Length (m) 0.288m
    Packaging 2 - Type box
    Packaging 2 - Volume (m³) 0.0087m³
    Packaging 2 - Weight (kg) 0.6kg
    Packaging 2 - Width (m) 0.178m
    UNSPSC Key 39131601
