Labels for control panel identification, thermal transfer : TAG20-08TE-1211-YE

Labels for Control Panel Identification for Thermal Transfer Printing 20x8 mm yellow, Article number: 596-11211


  • Suited to labelling electrical panels
  • Where high label visibility is required
  • Partially suitable for critical surfaces
  • Rounded corners ensure better long term durability of adhesion

Certifications & Approvals


These labels are suitable for the permanent identification of components and preassembled units within electrical industry as well as asset identification. Print with HellermannTyton’s premium range of thermal transfer printers and ribbons for optimum print results. They can also be used in the design and setup as well as in the repair and expansion of control cabinets and control units. Due to the structure of the vinyl label they are suitable for rougher surfaces.

Helatag 1211 (Yellow gloss) is suitable for following markets and industries

Application Tool TT431, TT4030
Colour Yellow gloss (GSYE)
Colour Marking Field Yellow gloss (GSYE)
Pack Cont. 10000pcs.
Package Quantity per reel
Product Family Helatag 1211 (Yellow gloss)
Product Group Labels for control panel identification, thermal transfer
Self adhesive (Yes/No) Yes
Short Description Labels for Control Panel Identification for Thermal Transfer Printing 20x8 mm yellow
Height (H) 8.00mm
HR 25.40mm
Print Method Thermal transfer
Thickness of Foil 84µm
VR 12.70mm
Width (W) 20.00mm
Width of Liner (WL) 101.60mm
Adhesive Acrylic
Chem. Material Properties Resistant to water, alcohol, most oils, greases, fuel, aliphatic solvents, weak acids, salts and alkalis.
Curing Temperature from +5 °C
ELV compliant (Article 4 - 2) YES
Halogenfree No
Hazardous good No
Material Type 1211, Vinyl, yellow gloss (1211)
Mech. material properties Permanent adhesive, suitable for critical surfaces.
Operating Temperature - °C -20 °C to +80 °C
Recommended Ribbon Type TT822OUT
EAN / GTIN 4031026296296
Labels per Row 4pcs.
Packaging 1 - Height (m) 0.115m
Packaging 1 - Length (m) 0.157m
Packaging 1 - Qty 1
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00265
Packaging 1 - Weight (kg) 0.54kg
Packaging 1 - Width (m) 0.147m
Weight 0.54kg
ETIM 6.0 EC001288
ETIM 7.0 Key EC001288
