26/09/2021
Colour shade can vary slightly from batch to batch from black to anthracite

Flame-retardand polyester braided sleeving : HEGPV008

Flame retardant braided sleeving black 8 mmArticle number: 170-30800

Features

  • Made of sturdy polyester
  • Self-extinguishing according to UL94 V0 for enhanced fire protection
  • Highly flexible
  • High abrasion resistance
  • High surface coverage

Certifications & Approvals

Application

HEGPV0 braided sleeving is used wherever fire protection is important such as in railway vehicles, machine tools, robotics and automatic equipment.

Application Tool HSG0
Colour Black with White Identification Yarn (BKIDWH)
Internet Customer Notice Colour shade can vary slightly from batch to batch from black to anthracite
Open, post termination (Yes/No) No
Pack Cont. 100m
Package Quantity per metre
PART DESCRIPTION HEGPV008-PBT-BK
Product Family Helagaine HEGPV0
Product Group Flame-retardand polyester braided sleeving
Short Description Flame retardant braided sleeving black 8 mm
Bundle ∅ max. 13mm
Bundle ∅ min. 7mm
Length (L) 100.0m
Nominal ∅ 8mm
Nominal ∅ 0.31"
∅ D 0.31"
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V0, FMVSS 302
Hazardous good No
Material Polyester (PBT)
Melting Point +225 °C
Operating Temperature - °C -50 °C to +150 °C
Specifications
GTIN-13 / EAN 4031026126104
Packaging 1 - Height (m) 0.07m
Packaging 1 - Length (m) 0.37m
Packaging 1 - Qty 100
Packaging 1 - Type reel
Packaging 1 - Volume (m³) 0.00958
Packaging 1 - Weight (kg) 1.27kg
Packaging 1 - Width (m) 0.37m
Packaging 3 - Height (m) 0.395m
Packaging 3 - Length (m) 0.38m
Packaging 3 - Qty 500
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0563
Packaging 3 - Weight (kg) 6.85kg
Packaging 3 - Width (m) 0.375m
Packaging 4 - Height (m) 1.329m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 9000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.276
Packaging 4 - Weight (kg) 144.3kg
Packaging 4 - Width (m) 0.8m
Reel Length 100m
Reel Length 328.0ft
ETIM 7.0 Key EC001182
UNSPSC Key 39131602
