FT6-PA66HIRHS-BK : FT6
Art.-No. 151-00912 | FT6-PA66HIRHS-BK |  Details

    Add to watchlist
    Downloads
    Colour Black (BK)
    Fixation Method Fir Tree
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    Pack Cont. 1000pcs.
    Package Content packed in bag
    PART DESCRIPTION FT6-PA66HIRHS-BK
    for Hole ∅ (FH) 6.4 - 7.1 mm
    for Panel Thickness min - max 0.8 - 3 mm
    Height (H) 13.8mm
    Length (L) 16.0mm
    Panel Thickness max. 0.75-3.0mm
    Width (W) 16.0mm
    Operating Temperature -40 °C to +105 °C
    Specifications
    Country of Origin CN
    GTIN-13 / EAN 4031026433974
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
