3X2WARNINGUV-336/926-OG : 3X2WARNINGUV
Art.-No. 596-00634 | 3X2WARNINGUV-336/926-OG |  Details

Pre-printed solar Warning label meets NEC and IFC standards for printed text, character height, color and outdoor UV stability to pass inspections.

    Add to watchlist
    Downloads Datasheet
    Colour Orange (OG)
    Material Type 336/926, Polyester, UV-stabilised, clear polyester laminate (336/926)
    Pack Cont. 250pcs.
    Package Content packed in roll
    PART DESCRIPTION 3X2WARNINGUV-336/926-OG
    H printable 50.8mm
    Height (H) 50.80mm
    HR 3.0"
    HR 76.2mm
    Thickness (T) 64.0µm
    VR 2.125"
    VR 79.37mm
    Width (W) 76.20mm
    Width of LIner (WL) 3.2"
    Width of Liner (WL) 81.2mm
    Adhesive Acrylic
    Adhesive Operating Temperature -40 °C to +150 °C
    CE Certification No
    CSA Certified No
    Curing Temperature +10 °C
    Halogen-free Yes
    Operating Temperature -40 °C to +150 °C
    Pre-Printed Yes
    Specifications
    Specifications ANSI Standard Z535.4, CSA 66956, IFC 2012, NEC2011, NEC2014, NEC2017, NEC2020, UL 969
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL-File Number MH14382, MH16736
    UV-Stabilised Yes
    Country of Origin US
    GTIN-13 / EAN 4031026471990
    Labels per Column 1
    Labels per Row 1
    Packaging 1 - Weight (kg) 0.521kg
    ETIM 7.0 Key EC001530
    ETIM 8.0 Key EC001530
    ETIM 9.0 Key EC001530
    UNSPSC Key 55121606
