Inventory and Name Plates Labels : NPL76X101BK

FOAM Series, Article number: 596-00557

Features

  • Adhesive labels made of vinyl, white gloss
  • Specially tailored to the sizes of IT marking ties and IMP tag range
  • Suitable for permanent marking of components and devices on different surfaces
  • Adheres to rounded surfaces
  • Excellent print performance using TT822OUT ribbon
  • Print with TT4000+, XXXNEW for best results
  • Easy label design with TagPrint Pro2 (version 3 coming soon)

Certifications & Approvals

Application

The use of our specially formulated adhesive labels printed on thermal transfer printers give the highest quality print clarity. The range of materials are complemented by ribbons developed to suit the needs of most users.
The production of labels is very simple. All that is needed is the required label to be selected from our industry leading software TagPrint Pro.

FOAM Series is suitable for following markets and industries

Colour Black (BK)
Pack Cont. 150pcs.
Package Quantity per roll
PART DESCRIPTION NPL76X101BK-PET-BK
Product Family FOAM Series
Product Group Inventory and Name Plates Labels
Self adhesive (Yes/No) Yes
Height (H) 101.60mm
HR 76.0mm
HR 3.0"
Print Method Thermal transfer
VR 4.125"
VR 104.77mm
Width (W) 76.2mm
Width of Liner (WL) 81.28mm
Width of LIner (WL) 3.2"
Adhesive Acrylate with base of acrylic foam
Adhesive Operating Temperature -40 °C to +80 °C
CSA Certified No
Halogenfree Yes
Material Polyester (PET)
Operating Temperature - °C -40 °C to +80 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
Labels per Column 1
Labels per Row 1
Packaging 1 - Weight (kg) 0.22kg
Weight 0.5lbs
Weight 0.22kg
ETIM 6.0 EC001288
ETIM 7.0 Key EC001288
UNSPSC Key 39131504
