Label, white, thermal transfer print, 30.00x20.00mm, H2=20.00mm, 1.000pcs.
Art.-No. 596-00159
| TAG20-50T1FL-934-WH
|
Copied
- Cable flag labels for permanent identification
- Easy handling for effortless installation and clearly visible legibility
- Legible on both sides for optimum visibility
- Other lengths and colours available on request
More products in this product group:
| Application | The Helatag 934 cable flag labels are ideal for permanent and clearly legible marking of cables and wires. Thanks to their special design, they offer clear, double-sided legible labeling, which is particularly advantageous in complex cabling. The robust material quality ensures high resistance to abrasion, moisture and external influences, making them perfect for use in demanding industrial and electrical installations. |
| Application Method | The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance. |
| Colour | White (WH) |
| Material | Type 934, Polypropylene, white (934) |
| PART DESCRIPTION | TAG20-50T1FL-934-WH |
| Pack Cont. | 1.000pcs. |
| Package Content packed in | box |
| Product Family | Helatag 934 |
| Product Group | Cable flag labels for cables and wires |
| Self adhesive (Yes/No) | Yes |
| Type | TAG20-50T1FL |
| Variant | Roller form |
|
|
| Bundle ⌀ | 2.0-5.0mm |
| Bundle ⌀ max. | 5.0mm |
| Bundle ⌀ min. | 2.0mm |
| H printable | 20.00mm |
| Height (H) | 30.00mm |
| Height (H2) | 20.00mm |
| Print Method | thermal transfer print |
| Thickness (T) | 123µm |
| Thickness of Foil | 19 |
| Weight/Unit | 0.001kg |
| Width (W) | 20.00mm |
| Width (W2) | 5.00mm |
| Width of Liner (WL) | 54.00mm |
| Width printable | 30.00mm |
Download
| Adhesive | Acrylic |
| Curing Temperature | from 0 °C |
| ELV compliant (Article 4 - 2) | YES |
| Hazardous Goods | No |
| Operating Temperature | -30 °C to +80 °C |
| ROHS compliant | Yes |
| Recommended Ribbon Type | TT822OUT |
| Shelf Life | Minimum 1 year upon receipt / maximal 2 years after production date. |
| Specifications |
|
|
|
Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability. ReSource highlights HellermannTyton products that are made from recycled waste or from virgin materials with relatively lower carbon emissions. |
| Country of Origin | DE |
| Customs Number | 39199080 |
| GTIN-13 / EAN | 4031026777993 |
| Labels per Row | 1pcs. |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | reel |
| Packaging 1 - Weight (kg) | 1.0kg |
| Packaging 2 - Qty | 1000 |
| Packaging 2 - Type | bag |
| Packaging 2 - Weight (kg) | 1.000001kg |
| Storage Temperature | +21 °C |
| Storage conditions | 50% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness. |
TT4030
556-04037
TT431
556-00400
