Fittings for Flexbile Metallic Conduits with Jacketed Cover
Art.-No. 166-90553
| FSU50-M50-M-NPB-ML
Copied
- Nickel plated brass compression fitting used with FSU, LFHU and FPU flexible metallic conduit.
- Two part fitting comprised of shell and body with external metric thread delivers IP54 ingress protection.
- Suitable for knockouts and secured with a metric threaded locknut.
| Brand Family | HelaGuard® |
| Color | Metal (ML) |
| Description | Two-part nickel plated brass straight fitting with fixed external metric thread. Fitting comprised of shell and body suitable for knockout entries. For use with FSU, FPU and LFHU flexible metal conduit. |
| PART DESCRIPTION | FSU50-M50-M-NPB-ML |
| Packaging Type | pack |
| Part No. | FSU50-M50-M |
| Short Desc. | Metallic Compression Fitting, Fixed Straight, M50 Metric Thread, 1.5" (50mm) Dia, NPB Metal, 1/pkg |
| Technical Description | Manufacturer Reference Number: FSU50-M50-M |
| Type | FSU50-M50-M |
| UV Resistant | No |
| Bore Diameter (metric) | 44.7 |
| Bore Hole Diameter (imperial) | 1.76" |
| Height (imperial) | 2.28" |
| Height (metric) | 58.0mm |
| Length (imperial) | 1.65" |
| Length (metric) | 42.0mm |
| Nominal Diameter (imperial) | 1.5" |
| Nominal Diameter (metric) | 50.0mm |
| Thread Length (imperial) | 0.59" |
| Thread Length (metric) | 15mm |
| Thread Size (metric) | M50 |
| Thread Type | metric |
| Trade Size | 1-1/2 " |
| Wrenching Flat Size | 42.0mm |
| Wrenching Flat Size | 1.65" |
