LTP40-125-EXD-NPB/PA6-ML
Art.-No. 166-90572 | LTP40-125-EXD-NPB/PA6-ML |

Copied

    Add to watchlist
    Downloads
    Colour Metal (ML)
    Material Nickel Plated Brass (NPB), Polyamide 6 (PA6)
    PART DESCRIPTION LTP40-125-EXD-NPB/PA6-ML
    Pack Cont. 1pc.
    Package Content packed in pack
    Thread type NPT
    Type LTP40-125-EXD
    Variant Straight
    Bore Diameter (Imperial) 1.20"
    Bore Diameter (metric) 30.4
    Height (H) 52.0mm
    Length (L) 53.0mm
    Nominal ⌀ 1.25"
    Nominal ⌀ 40.0mm
    Thread Length (TL) 20mm
    Thread Length (TL) (Imperial) 0.79"
    Thread Size (Imperial) 1-1/4 "
    Wrenching Flat Size (Imperial) 1.53"
    Wrenching Flat Size (Metric) 38.8mm
    CSA Certified No
    Halogen-free Yes
    IP-Rating IP68
    Operating Temperature -60 °C to +85 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026560441
    UNSPSC Key 39131707
