LTPPU16BU-25M-GS/PUR-BU
Art.-No. 166-90723 | LTPPU16BU-25M-GS/PUR-BU |

Copied
Flexible metallic conduit provides liquid-tight performance to IP66 + IP67 + IP68 + IP69 when used with LTP or LTPUL fittings.

    Add to watchlist
    Downloads
    Colour Blue (BU)
    Material Galvanised Steel (GS), Polyurethane resin (PUR)
    PART DESCRIPTION LTPPU16BU-25M-GS/PUR-BU
    Pack Cont. 25.0m
    Package Content packed in reel
    Type LTPPU16BU-25M
    ⌀ D 0.49"
    Bending Radius min. (R) 45mm
    Diameter (D) 12.6mm
    Length (L) 25.0m
    Nominal ⌀ 0.38"
    Nominal ⌀ 16.0mm
    Outside ⌀ (OD) 17.8mm
    Outside ⌀ (OD) 0.70"
    Weight 311g/m
    CE Certification Yes
    CSA Certified No
    Flammability UL 94 V0
    Halogen-free Yes
    Operating Temperature -40 °C to +100 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026562360
    Packaging 1 - Weight (kg) 7.78kg
    Reel Length 82.0ft
    Reel Length 25.0m
    UNSPSC Key 39131706
    Metal conduits Metal conduits

    Metal conduits

    Metal conduits from HellermannTyton: Standard metal conduits, coated metal conduits, liquid tight metal conduits and matching metal conduit fittings. Discover now!
