29/03/2024

LTS075-90FMC-M25-NPB/PA6-ML : LTS075-90FMC-M25
Art.-No. 166-90432 | LTS075-90FMC-M25-NPB/PA6-ML Details

Colour Metal (ML)
Material Nickel Plated Brass (NPB), Polyamide 6 (PA6)
Pack Cont. 10pcs.
Package Content packed in pack
PART DESCRIPTION LTS075-90FMC-M25-NPB/PA6-ML
Thread type metric
Variant 90°-elbow
Bore Diameter (Imperial) 0.71"
Bore Diameter (metric) 18.0mm
Height (H) 35.0mm
Length (L) 49.0mm
Nominal ∅ 25.0mm
Nominal ∅ 0.75"
Thread Length (TL) 14mm
Thread Length (TL) (Imperial) 0.55"
Thread Size M25
Wrenching Flat Size (Imperial) 1.93"
Wrenching Flat Size (Metric) 39.0mm
CE Certification No
CSA Certified No
Halogen-free Yes
IP-Rating IP68
Operating Temperature -50 °C to +135 °C
Specifications
UL Listed (US and Canada) Yes
UL Recognized (US and Canada) No
UL-File Number E247502
UV-Stabilised (Yes/No) No
Country of Origin GB
GTIN-13 / EAN 4031026521060
UNSPSC Key 39131707
